| · | Screen Size 17" FST / 40.7 cm | · | Dot pitch 0.27 mm |
| · | Horizontal pitch 0.24 mm | · | Vertical scanning 50 - 150 Hz |
| · | Video Band Width 110 MHz(-3dB) | · | Active Display (4:3 Ratio) Horizontal 306mm, Vertical 230mm |
| · | Max. resolution 1280 x 1024 | · | Recom. resolution 1024 x 768 |
| · | H. freq (kHz)/V. freq (kHz) 640 x 480 to 1280 x 1024
640 x 480 31.5K/60; 43.2K/85; 50.6K/100
720 x 400 31.5K/70
800 x 600 46.8K/75; 53.6K/85; 63.9K/100
832 x 624 49.7K/74.5
1024 x 768 60.0K/75; 68.6K/85
1152 x 864 67.5K/75
1280 x 1024 64.0K/60 | · | Plug and play compatibility see attached link.
Display Data Channel DDC 1/2B
Microsoft ® , Windows ® 95/98/NT compatible |
| · | Power management see attached link.
Operation ( typ.) Complies with EPA Energy Star and NUTEK specifications 78 W, Suspend/Stand By mode ( typ.) < 8 W, Off mode/ Deep Sleep < 2.5 W. | · | Low-emission characteristics Complies with TCO99 specifications |
| · | Monitor controls and functions Jog Shuttle with on screen Display
Pincushion, Pin Balanced, Trapezoid, Parallelogram, Rotation,
Corner Pin, Brightness, Contrast, H/V Position, Recall, H/V moire | · | Connections and Cables Video and Power
|
| · | Regulatory approvals click above link.
Regulatory approvals
TCO99 Low Emission
TüV/GS, VESA, DMPS, EPA
FCC, UL, C-UL, DHHS
Scandinavians(S, N, D,Fl)
VCC-I, CE, BCIQ, PSB | · | Net Dim. (WxHxD)(mm) 414 x 432 x 414.5 |
| · | Gross Dim. (WxHxD)(mm) 477 x 443 x 414.5 | · | Net Weight (kg) 15.0 kg |
| · | Gross Weight (kg) 18.2 kg | · | Power supply 100 - 240 VAC, 50/60Hz |
| · | Temperature (operational) 0°C to +40°C | · | Temperature (storage) -20°C to +45°C |
| · | Options USB Hub & Mac Adapter option | · | Horizontal scanning 30 - 70 KHz |
